Wooden floor trailer question


Post new topic   Reply to topic    The Smoke Ring Forum Index -> Cookers
View previous topic :: View next topic
Author Message
ClydeDale
Newbie


Joined: 21 Aug 2009
Posts: 38
Location: Hopkinsville, KY

PostPosted: Tue Mar 01 11 9:46 am    Post subject: Wooden floor trailer question Reply with quote

I have 250 gallon reverse flow smoker and a 20" X 60" charcoal grill that I am wanting to mount to a trailer. I have a 6 X 12 utility trailer with a 3500 Lb. axle, 15" wheels and a 2" X 12" pressure treated deck. What are your thoughts concerning a wooden floor vs a metal floor? I have priced 3 4' X 8' sheets of 1/8" diamond plate but that's a $4.00.00 adder.
Back to top
View user's profile Send private message
Get Your Rub On BBQ
BBQ Fan


Joined: 12 Oct 2008
Posts: 333
Location: Cordova, TN

PostPosted: Tue Mar 01 11 9:51 am    Post subject: Reply with quote

What's the spacing of the trailer floor cross members? Depending on the weight distribution/leg placement you may see some bowing in the ATP after a few trips up and down the road. You are talking steel ATP vs. aluminum right?
_________________
James Stephens
Extreme BBQ Trailers
www.extremebbqtrailers.com
Back to top
View user's profile Send private message Send e-mail Visit poster's website
ClydeDale
Newbie


Joined: 21 Aug 2009
Posts: 38
Location: Hopkinsville, KY

PostPosted: Tue Mar 01 11 10:39 am    Post subject: Reply with quote

The supports are 2" X 3 " on 24 " centers. The bottom of the tank will be about 14" from the trailer floor; I hopr this helps.
Back to top
View user's profile Send private message
solanabeacher
BBQ Super Fan


Joined: 28 May 2009
Posts: 429

PostPosted: Wed Mar 02 11 12:24 am    Post subject: Reply with quote

Here is what I did............





Back to top
View user's profile Send private message
k.a.m.
BBQ Mega Star


Joined: 12 Dec 2007
Posts: 26019
Location: Southeast Texas.

PostPosted: Thu Mar 03 11 9:33 am    Post subject: Reply with quote

ClydeDale, if you go tread plate I would up the thickness to 3/16". 1/8" tread plate is not gonna cut it with 24" center cross members in my opinion.
_________________
Always remember slow and steady wins the race.

Hybrid Cooker
Back to top
View user's profile Send private message
TrailerBuilder
BBQ Super Pro


Joined: 08 Feb 2010
Posts: 3151
Location: Springfield MO

PostPosted: Thu Mar 03 11 11:27 am    Post subject: Reply with quote

ClydeDale, I have to agree with k.a.m. on this one. If you go with 1/8 tread, you will need 12"-14" centers. By the time you add the extra $$$ in crossmembers, you might be about the same amount of the 3/16th matieral.

Just my 2c worth.
