 Posted: Apr 19 2009 Post subject: |
 |
|
Those are fantastic. Thanks for the pics.
That's some serious propane pipe work. How about some pics of the inside under the grates?
_________________
D. Tillery
Texan transplanted in Billings, MT
www.mrcustomsteel.com |
|
| Back to top |
|
 |
handz98
Newbie
Joined: 02 Sep 2008
Posts: 76
Location: Champaign, IL
|
| Posted: Apr 19 2009 Post subject: |
|
|
| purplewg wrote: | | Hole Cow. You don't even have to butcher them they can just walk right in. |
Now that's funny...awesome build!!!
_________________
Peoria Custom Cookers 24" x 48" Trailer |
|
| Back to top |
|
|
hapyjak
Joined: 01 Feb 2009
Posts: 24
|
| Posted: Apr 22 2009 Post subject: |
|
|
| mrcustomsteel wrote: | Those are fantastic. Thanks for the pics.
That's some serious propane pipe work. How about some pics of the inside under the grates? |
manifold system to six 3/4" pipe burners with vinturis. the two inch elbows are vents, which are good enough to keep the coals in good shape but not enough supply to keep the gas burning if you shut the lid. but tey sure light up the charcoal in a hurry and in a pinch with the lid cracked open they burn true.
under the charcoal grates and on top of the burners are 2" angle deflectors
the pipe burners with holes drilled every 1/2"
the other side is the offset smoker, no tuning plates. i placed my exhaust stack 6 inches from the bottom, there is a 5-10° difference between left to right and about a 15° difference between top and bottom shelf. no hot or cold spots. |
|
